GP-CH420F
    Industrial Label Printer
    ดาวน์โหลดโบรชัวร์
    รายละเอียด

    -

    Printing Specifications
    Print MethodThermal Transfer / Direct Thermal
    Print Speed2~12inch/s2~10inch/s
    InterfaceUSB+Serial+Ethernet
    Print Resolution203dots / inch (8dots /mm )300dots / inch (11.8dots /mm )
    Memory16MB RAM+8MB Flash
    Dot size1mm=8dots1mm=11.8dots
    Printing width104mm106.7mm
    Max. Printing Length1500mm(59”)1500mm(59”)
    Printer Dimensions
    Printer Dimensions 425x255x265mm(WxDxH)
    Weight9.65 KG
    Working EnvironmentTemperature: 5~45 (41~104 ), Humidity: 25~85%RH
    Storage EnvironmentTemperature: -10~50 (-10~140 ), Humidity: 10%~90%RH
    Pulse excitation1x10 Pulses
    Ribbon Consumables
    Ribbon ODMax.81.3mm
    Ribbon Length450m
    Ribbon Core Sizelinch (2.54mm)
    Ribbon WidthMax. 110 mm Min. 30 mm
    Ribbon Rolling Up MethodOutward Rolling
    Paper Consumables
    Media Roll OD203 mm (8*) OD
    Media TypeContinuous, black mark, gap, punched hole, Fan fold and more labels
    Media Rolling Up MethodPrinting side outward rolling
    Media WidthMax.120mm (4.72”) Min.20mm (0.78”)
    Media ThicknessMax. 0.254mm (10mil) Min. 0.06mm (2.36mil)
    Media Roll Core Size25.4 mm - 38 mm (1 - 1.5 )
    Media GapMin. 2 mm (0.09”)
